2025 Yamaha TW200

  • 2025 Yamaha TW200
  • 2025 Yamaha TW200
  • 2025 Yamaha TW200
  • 2025 Yamaha TW200
  • 2025 Yamaha TW200
  • 2025 Yamaha TW200
  • 2025 Yamaha TW200
  • 2025 Yamaha TW200
  • 2025 Yamaha TW200

CURRENT PROMOTIONS

Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo  Print
Overview

A low seat, extra-wide tires, and a proven four-stoke engine have cemented the TW200's reputation as a unique, fun-loving dual purpose ride. Whether you're a beginner or a veteran, a camper or a city dweller, this bike guarantees good times.

Specifications
Model
TW200
Category Name
Motorcycles
Year
2025
Sale Type
New
Manufacturer
Yamaha
Color
Radical Grey
Province
Ontario
engine
ENGINE
Air-cooled, SOHC, 2-valve, single
FINAL DRIVE
Chain
DISPLACEMENT
196cc
TRANSMISSION
Constant mesh, 5-speed
FUEL DELIVERY
Teikei MV28
MAXIMUM TORQUE
1.4kg-m (10.1ft-lb)@ 7,000 rpm
BORE AND STROKE
67 x 55.7mm
COMPRESSION RATIO
9.5:1
IGNITION / STARTING
CDI / Electric Start
ESTIMATED FUEL CONSUMPTION±
33kpl / 93.2mpg (Imp.)
chassis
TIRES (REAR)
180/80-14
BRAKES (REAR)
Drum
TIRES (FRONT)
130/80-18
BRAKES (FRONT)
220mm disc / twin piston caliper
SUSPENSION (REAR)
Monocross / 150mm (5.9") wheel travel
SUSPENSION (FRONT)
33mm fork / 160mm (6.3") wheel travel
highlights

2025 Yamaha TW200ENGINE

The TW's proven, 196 cc, air-cooled, four-stroke single delivers torquey low- and mid-range power perfectly suited to off-road exploring or riding around town.

2025 Yamaha TW200COMFORT

An internal engine counterbalancer provides smooth performance while wide tires provide plenty of grip and a unique style. The long, wide seat design means lots of comfort whether exploring, commuting or just out having fun.



key features
  • ​Electric starting.
  • Single overhead camshaft (SOHC), 2-valve cylinder head.
  • Automatic cam chain tensioner.
  • Aluminum cylinder features a cast iron liner.
  • Lightweight ball-bearing-mounted crankshaft.
  • Engine counterbalancer.



critical data
WIDTH
820mm (32.3")
HEIGHT
1,120mm (44.1")
LENGTH
2,090mm (82.3")
COLOUR(S)
Gallant Grey
WHEELBASE
1,325mm (52.2")
WET WEIGHT
126kg (278 lb)
SEAT HEIGHT
790mm (31.1")
FUEL CAPACITY
7 litres (1.5 imp. gallons)
GROUND CLEARANCE
265mm (10.4")
features & benefits

ENGINE

  • Super reliable, 196 cc, air-cooled, SOHC, 2-valve single delivers torquey low- and mid-range power perfectly suited to off-road exploring or riding around town.
  • Electric starting.
    • Fast, easy, no-hassle starting
  • Single overhead camshaft (SOHC), 2-valve cylinder head.
    • basic design for easy, less expensive maintenance
    • 34 mm intake and 28.5 mm exhaust valves
    • utilizes easy to adjust conventional rocker arms and screw-type tappet adjusters
  • Automatic cam chain tensioner.
    • reduces mechanical engine noise and maintenance
  • Aluminum cylinder features a cast iron liner.
    • cylinder can be "bored out" in the event of a problem (2 sizes available)
  • Lightweight ball-bearing-mounted crankshaft.
    • excellent durability
    • fast engine response
  • Engine counterbalancer.
    • reduces engine vibration to maximize rider comfort
  • 28 mm Teikei carburetor
    • carb-mounted choke knob
    • provides crisp throttle response
    • excellent fuel economy
  • Washable, foam air filter reduces maintenance costs.
  • Easy-access element-type oil filter and drain plug for fast oil changes.
  • Smooth-shifting 5-speed transmission with manual clutch.
    • optimized gear ratios for both on- and off-road riding
    • 5th gear is an overdrive gear to reduce engine rpm at highway speeds
  • Up-swept exhaust system
    • exhaust note is quiet and environmentally friendly
    • cleanable spark arrestor
    • heat shields on header pipe and muffler protect rider and passenger from accidental contact
  • Maintenance-free capacitor discharge ignition (CDI).
    • produces a strong spark for fast starts
    • provides precise ignition timing/mapping for optimum engine performance at all rpm
  • Rugged, aluminum engine skid plate

CHASSIS

  • Compact, diamond-type, high-tensile steel frame.
  • Rugged, steel box-section swingarm.
    • grease fittings at the swingarm pivot points for easy maintenance and extended service life
    • fitted with easy-to-use eccentric chain adjusters
  • 33 mm front fork with 160 mm (6.3") of wheel travel
    • soaks up the bumps for a comfortable ride
    • rubber fork boots (gaiters) keep dirt and grit out of fork seals for extended life
  • Single-shock Monocross link rear suspension with 150 mm (5.9") of wheel travel.
  • 220 mm front disc brake with twin piston caliper
    • ensures serious stopping power
  • Rear drum brake
    • solid stopping power
    • easy-to-use, wing-nut-style adjuster
  • Wide, 130/80-18 front tire and unique 180/80-14 rear tire.
    • deliver extra traction and great rider comfort over a wide range of terrain
    • rear tire helps make TW200 the most distinct-looking dual purpose machine in the industry
  • Low, 790 mm (31.1") seat height
    • allows most riders to put both feet firmly on the ground.
  • 7-litre steel fuel tank
    • on/off/reserve fuel petcock provides peace of mind
    • 1.7-litre reserve
  • Lightweight aluminum alloy front and rear rims
    • excellent durability
    • reduces unsprung weight for optimal suspension performance
  • Powerful, 60/55-watt, halogen headlight
  • Mini, enduro-style fairing
    • helps reduce wind buffeting at highway speeds
    • adds a styling highlight too.
  • Compact meter / instrument assembly
    • functions include: speedometer, odometer & resettable trip meter
    • indicator lights for neutral, high beam & turn signals
    • retro paint and graphics

DETAILS

  • Flexible turn signals resist damage
  • Oil level sight glass
  • Locking helmet holder
  • Locking steering and gas cap
  • Handy rear cargo platform
  • Bungee cord hook points (4), below the cargo platform
  • Serrated, folding, steel foot pegs
  • Passenger pegs and passenger grab strap
  • Rubber "boots" on brake and clutch levers help reduce mud & dirt damage/wear
