2022 Yamaha SIDEWINDER L-TX GT EPS

Call Email

In Stock

Location:
Dennis Motors

$12,995 CAD

Tax Not Included

Contact Us Get Approved Value a Trade Get Directions Get Directions Print

Province

Prince Edward Island

Model

SIDEWINDER

Category Name

Snowmobiles

Sale Type

Manufacturer

Yamaha

4UF8S4LK7NT102752

Color

Ink Blue & Regal Gold

Class

CodeName

SW1NLGPNL

Model Code

Sidewinder LTX GT - Chancy Norton

Titlestatus

CLEAN

Unitcondition

EXCELLENT

Model Code

Sidewinder LTX GT

Province

Prince Edward Island

features

REVERSE

Standard

COLOUR(S)

Ink Blue/ Regal Gold

DC OUTPUT

Automotive & RCA

HEADLIGHT

HEATED SEAT

Standard

ELECTRIC START

Standard

ELECTRIC POWER STEERING

Standard

Yamaha Electric Power Steering - 'EPS'

The newest generation has reduced weight by over 3 pounds and incorporates a ‘brushless’ DC motor. No brushes to wear out means greater reliability and much better thermal performance or ability to maintain full output power for longer periods of time. Variable assist EPS utilizes a magnetic torque sensor to measure steering input based on torsion or 'twist' of the steering post resulting from handlebar input combined with ski resistance. The contact-less, magnetic torque sensor supplies this data to an integrated 'control module' which in turn, signals the brushless 'servo-motor' to assist the steering through its powered, worm-gear 'drive assembly'. The system also provides engine 'rpm' and vehicle 'speed' data to the control module which calibrates for increased assistance at lower speeds then tapers off as the vehicle accelerates giving a more balanced, natural feel or 'connection' to the terrain. When the skis encounter an abrupt force that works against the steering input, the torque sensor alerts the control module to apply additional assistance to counteract or ‘resist’ the negative input. This effectively reduces the steering effort required while enhancing predictability for greater rider confidence and less fatigue.

Rear Hard Case with Auxiliary Fuel Tank

You wont be caught short on a long ride with the convenient, moisture proof, hard storage case and 4 usg / 16 liter auxiliary fuel tank. Total fuel capacity is bumped up to 13 usg / 50 liters, which goes a long ways on the trail (and your peace of mind).

Premium Fox QS3 Front Shocks

The Sidewinder S-TX GT sports front Fox QS3 adjustable shocks up front and aluminum body HPG ( High Pressure Gas) shocks in the rear, offering fade free performance to handle all the challenges the trail can dish out.

SKI TYPE

Yamaha Stryke Single Keel

REAR TRAVEL

14.5" (368 mm)

CENTRE SHOCK

Monotube Alum-HP Gas 1.5

FRONT SHOCKS

Fox Zero QS3 1.5

FRONT TRAVEL

10" (254 mm)

REAR SHOCK(S)

Monotube Alum-HP Gas 1.5

REAR SUSPENSION

Dual Load 146

FRONT SUSPENSION

Independent Double Wishbone

Turbo 4-stroke / 998 cc

CLUTCH

ENGINE CLASS

Ultra Performance

FUEL CAPACITY

13 gal. (50 L) combined

FUEL DELIVERY

Electronic Fuel Injection

Key Features

146 Dual Load Rear Suspension
Deluxe 2-Piece Heated King Queen Seat
Rear Hard Case with Auxiliary Fuel Tank
998 Genesis Turbo Engine
Premium Fox QS3 Front Shocks.
Front / Rear Adjustable Hand Warmers
Electric Power Steering

TOP

The Dual Shock SR 146 offers a long profile version of our acclaimed trail comfort suspension. This lightweight suspension offers premium bump compliance with excellent resistance to bottoming. The Dual Load 146 is a “coupled” skid-frame that utilizes a unique “sliding” front arm mount with half an inch of movement at the front arm “slot”. This active arm design delivers controlled (reduced) ski-lift during acceleration while retaining a good measure of independent front arm tracking. The addition of passenger 'overload' springs help compensate for the extra weight of a passenger to reduce bottoming and maintain balance.
A plush 2-up heated seat provides the ultimate in warmth and comfort on even the coldest of winter days. A simple flip of the dash-mounted switch allows you to choose from two settings of warmth and your passenger has their own controls. The passenger also gets a fully adjustable backrest.
The SRV front suspension geometry is aimed at managing spindle camber, resulting in minimized bump-steer and maximized cornering bite giving rider confidence in varying trail conditions. The A-arms are mounted at a 30-degree angle from the sled's centerline to efficiently dissipate impact force throughout the entire chassis. Likewise, the front shocks mount directly to the leading spar so that trail forces are routed to the strongest part of the chassis. Wide a-arm spacing minimizes flex and stress in the front suspension system, which means consistent and confident corner handling.
You wont be caught short on a long ride with the convenient, moisture proof, hard storage case and 4 usg / 16 liter auxiliary fuel tank. Total fuel capacity is bumped up to 13 usg / 50 liters, which goes a long ways on the trail (and your peace of mind).
The turbo boosted, one liter triple is unmatched when it comes to delivering incredible power with the refinement and quality you have come to expect from a Yamaha. Designed around a premium turbo unit, every engine component from intake to exhaust, is dedicated to producing uncompromised performance. The Yamaha turbo has earned the respect and reputation befitting the industries highest achiever. Truly this is the potent venom of a Sidewinders bite.

PERFORMANCE

Yamaha wanted an engine that's exceptionally quick to respond with little or no 'lag' as found in a conventional turbo. One of the ways they achieved their goal was to develop an intake system using three separate throttle bodies positioned very close to the intake valves. Instead of just one feeding long intake tubes — something that is not seen in any other production turbo on the planet. And another first for Yamaha with the Genesis turbo.
The Nickel alloy turbine body is extremely strong and precise, able to withstand highly elevated temperatures. Supported by premium, ceramic ball bearings, the Inconel turbine blade assembly is very light and strong. This yields a low moment of inertia for lightning quick response to exhaust gas input. Triple throttle bodies are used exclusively to further enhance the quick delivery of compressed air from the impeller to intake valves.
The Yamaha-developed Mitsubishi ECU uses a series of 9 sensors to gather running condition data which it computes using a predetermined memory ‘map’. It then adjusts ignition timing, fuel delivery, manifold air-pressure and turbo boost pressure to produce maximum performance under any condition - reliably.
The SRV chassis combines a load-bearing triangulated structure with lightweight aluminum construction to create a neutrally balanced sled that's centered on the rider. The pyramidal upper frame creates chassis strength without excessive weight.

HANDLING

The effect of 4-stroke 'engine braking' when the throttle valves are closed has a significant impact on handling and ride character. Yamaha developed a special system which employs the ISC (idle speed control) circuit and ECU map using throttle valve movement and RPM information to reduce negative intake pressure during deceleration.
Regarded as the best high-performance terrain track available, the 146 inch x 1.25-inch lug design of the RipSaw delivers incredible acceleration, braking control, and handling in a wide variety of conditions.
The Sidewinder S-TX GT sports front Fox QS3 adjustable shocks up front and aluminum body HPG ( High Pressure Gas) shocks in the rear, offering fade free performance to handle all the challenges the trail can dish out.
The Yamaha design, single keel ski, strikes the elusive balance between lightweight steering effort and precision handling over a wide range of snow conditions. Special staggered carbides further enhance steering response. A unique EPS shim pad assembly works in conjunction with the rubber saddle block to adjust the carbide pressure point. Overall ski stance is also adjustable by relocating the thick spacer located on each ski axle to the opposite side.

COMFORT

Both driver and passenger are provided convenient RCA DC outlets for heated helmet visors plus a socket type outlet located in the console to power-up other 12V accessories.
Both driver and passenger stay toasty warm with independently controlled hand warmers. The passenger also gets functional wind deflectors added to the padded rear grab bars to help keep the elements away from their hands.
The medium smoked polycarbonate windshield was designed to shield the high-mileage rider from the coldest days. The windshield incorporates a small lip at the top to deflect wind and snow up and over the rider at speed, while flared edges provided added protection and warmth for your hands. The GT windshield was also designed to accomodate optional mirrors. The windshield is thicker then standard windshields to reduce mirror vibration at speed and features pre marked indents for an easy installation of the accessory mirrors.
The handle bar controls feature a left hand switch cluster which allows for 'on the fly' access to the multi-step hand and thumb warmer adjusters. Information available on the multi-function gauge can be easily selected with a convenient toggle switch and the push button reverse gear switch is also located in the left hand cluster. The right side of the bar is clean with an ergonomically shaped throttle lever and simple, stand-alone emergency stop switch. The Hayes 'Stealth' brake cylinder is equipped with a composite brake lever providing great modulation for better feel and powerful stopping performance.

measurements - dimensions

TRACK TYPE

Camso Ripsaw I

TRACK / W X L X H

15" x 146" x 1.25"

SKI STANCE (CTR TO CTR)

42" (1,067 mm) adjustable
